Air dryer
The TDAD series airflow dryer is an ideal piece of equipment for drying starch, modified starch, and potato starch in the starch industry. Starch dried using this equipment is guaranteed to be of high quality, clean, smooth, glossy, and with stable moisture content. It also ensures high water absorption, good activity, and original quality of wheat and potato starch. This equipment can be designed and manufactured according to the customer's site space and warehouse layout, facilitating installation, operation, and maintenance. The airflow velocity changes constantly due to the different diameters of the expansion joints, resulting in high heat transfer and excellent drying effect. The annular airflow dryer is specifically designed for wheat and potato starch and B starch to ensure thorough drying and refining of the product. Under normal operation, the average drying time is only a few seconds. The drying temperature can be adjusted according to the characteristics of the raw materials. This equipment has a simple and compact structure, low budget, and is easy to operate.
Product Details
Advantages:
Strict welding standard: Firm, aesthetic weld seams; sheet metal & square tubes welded at perfect vertical angles, zero misalignment.
Full post-weld finishing: Complete weld slag removal, thorough grinding for smooth, flawless surfaces; all burrs, flash edges on holes and panels fully eliminated.
Sharp edge deburring & blunting: All sharp corners and sharp edges rounded off to avoid scratches and safety hazards.
Deformation control system: Stress relief annealing + flat straightening processes to minimize post-processing distortion, ensure flatness meets strict tolerance standards.
Dual fastening solution: Bolts & nuts fully tightened then spot-welded for ultra-reliable, long-lasting connection.
Complete pre-assembly inspection: Every finished cabinet undergoes trial fitting with brackets and covers, all bolts fit smoothly without assembly interference.
Uniform matte sand-texture powder coating with precise thread protection during spraying.
Consistent color coverage, free of pinholes, shrinkage cavities and paint sagging; coating thickness complies with official technical specifications.
Shot blasting pre-treatment before powder coating to boost coating adhesion, anti-rust and anti-corrosion performance.
Quality control system：
Every production step is inspected from raw material forming, welding, surface finishing to pre-assembly testing, with all dimensional, appearance, electrical and corrosion indicators strictly aligned with international technical standards, delivering stable, durable and high-standard custom metal & busbar solutions.
Product Parameters
Model | Feed starch moisture(%) | Discharge starch moisture(%) | Starch production(t/h) | power(kw) |
TDAD-0.5 | ≤40 | 12-14 | 0.5 | 21.3 |
TDAD-0.8 | ≤40 | 12-14 | 0.8 | 24.3 |
TDAD-1 | ≤40 | 12-14 | 1 | 26.6 |
TDAD-1.2 | ≤40 | 12-14 | 1.2 | 30.1 |
TDAD-1.6 | ≤40 | 12-14 | 1.6 | 40.6 |
TDAD-2 | ≤40 | 12-14 | 2 | 47.6 |
TDAD-2.6 | ≤40 | 12-14 | 2.6 | 59.5 |
TDAD-3.2 | ≤40 | 12-14 | 3.2 | 75 |
TDAD-3.6 | ≤40 | 12-14 | 3.6 | 95 |
TDAD-5 | ≤40 | 12-14 | 5 | 123.4 |
TDAD-6 | ≤40 | 12-14 | 6 | 170 |
TDAD-10 | ≤40 | 12-14 | 10 | 223.5 |
TDAD-15 | ≤40 | 12-14 | 15 | 321 |
TDAD-20 | ≤40 | 12-14 | 20 | 420 |
